Z-2

Z-2

Bookshelf Speaker

QUAD proudly announce Z Series, our new flagship ribbon loudspeaker range. After taking a new approach to ribbon tweeter design using a unique sandwich formation, an exceptionally robust, high power speaker has been engineered, yet with the delicate sound, conventional ribbon speakers are known for. Z Series is housed beautifully curved piano lacquered cabinets, available in black, white and rosewood.
Color
View full details
  • Overview
  • Specifications
  • Downloads
  • Reviews
  • Related Products

Specifications

Model Z-2
General description bookshelf
Enclosure type bass reflex
Transducer complement 2-way
Bass driver 175mm glass fibre
Treble driver 90x12mm true ribbon
AV shield No
Sensitivity (1W @ 1m) 84db
Recommended amplifier power 40-200w
Nominal impedance
Minimum impedance 4.6Ω
Frequency response (+/-3dB) 50Hz - 20kHz
Bass extension (-6dB) 45Hz
Crossover frequency 3.4kHz
Cabinet Volume (in litres) 15L
Dimensions (mm) 421 x 243 x 329
Weight 9kg
